Lower Total Cost of Ownership
Like all Doosan ‘-5’ excavators above 20 tonne, the DX225SLR-5 incorporates a thicker inside plate in the arms and booms, providing front reinforcement to relieve stress concentration and a different welding method has also been applied. To further maximise durability and reduce noise, all ‘- 5’ models are equipped with EM (Enhanced Macro-surface) bushings, which are also much more effective than regular bushings when greased.
Air pre-cleaners are fitted as standard on the DX225SLR-5, to blow much of the dust, dirt, insects, rain and snow out of the air intake, to ensure cleaner air is sent to the engine air filter. This extends air cleaner servicing intervals, enhancing uptime and productivity. Doosan has also added protection to the inner cab air filter and redesigned the cab air-conditioning filters for easier replacement.
A Trimble Ready option is available for the DX225SLR-5, enabling a faster and simplified installation of Trimble® 2D or 3D Grade Control System components − with no welding, repainting, drilling or disassembly required.
For more on Doosan construction equipment, visit the website:
Brief specifications for the Doosan DX225SLR-5 excavator
• Operatingweight: • Diggingdepth:
• Diggingreach:
• Diggingheight:
• Overallwidth(with800mmshoes): • Height:
• Overalllengthintravelposition:
24.4 tonne 11650 mm 15380 mm 13075 mm
3190 mm
3275 mm 12360 mm
• Rear swing radius:
• Digging force over bucket (ISO): • Digging force over arm (ISO):
• Travel speed:
• Engine (SAE J1995 net): Stage IV (EGR/SCR),
2795 mm 10.0 tonne 6.0 tonne low range – 3.0 km/h high range – 5.5 km/h 6-cylinder Doosan DL06P 124 kW (166 HP) at 1800 RPM Nov 2018 - Issue 53
