News
The new lighting concept with LED headlights ensures improved visibility and safety – both for the machine operator and everyone in the outdoor area. For example, dipped-beam headlamps with integrated high beam illuminate the road and the extra powerful, optional LED headlights on the front of the can illuminate the entire working area. The lighting at the rear of the trough and another light package at the mudguards light up the manoeuvring areas at night. The modern LED design light provides additional visibility of the Liebherr dump truck and thus increased safety on the construction site. The new Liebherr dump truck also has an optional LED access light which provides extra safety when getting into the operator's cab.
Modern assist systems and adaptive steering system increase comfort and safety
The modern assist systems installed in the new TA 230 Litronic support the machine operator, thus increasing safety and comfort during operation. Apart from a hill start assist, a speed assist is also available. With the hard stop function, the end position damping of the trough lifting cylinders can be activated or deactivated at the touch of a button. The trough lift is limited for work in a height-critical area with the aid of the height limit.
The speed-dependent steering provides additional driving comfort: The adaptive steering system continuously adapts the ratio of the steering movements to the current speed. This makes possible easy and accurate manoeuvring at low speeds, butalsoaccuratesteeringathigherspeeds,aswellasfewer steering corrections when cornering or taking bends.
Maintenance-friendly machine design
With the intelligent machine check-up and a service-oriented machine design, the new TA 230 Litronic boasts an optimised maintenance concept. The Liebherr dump truck automatically performs the daily check itself thanks to the clever sensor technology: The machine runs through an inspection catalogue at the start, where levels of engine oil, coolant, the central lubrication system, for example, are checked for the nominal state. Any deviations are shown on the display in the operator's cab. As a result, the daily set-up times can be reduced, costs can be saved, and the durability of the components can be extended.
The electrohydraulic opening bonnet, as well as an integrated, folding ladder with non-slip steps, provide easy, safe, and clear access to the entire engine compartment. All relevant service points are visible and easily accessible. Maintenance work can be performed comfortably and safely from a platform. Refuelling with fuel or urea solution is also done easily and safely from the ground.
Key performance data of the TA 230 Litronic in standard version at a glance:
• Emptyvehicleweight:24,600kg
• Payload:28,000kg(metrictons)
• troughcapacitywithtailgate:18.1m3
• Enginepower(ISO9249):265kW/360hp
• ExhaustemissionsstandardV
• Drivingspeed:57km/h(forward)/16km/h(reverse)
