Crushing & Screening
First MT120J from MAGNA heads to
Australia for large-scale operations
MAGNATM, the Terex brand established to
meet the growing demands of large-scale
operations, is pleased to announce the
completion of the first MT120J large jaw
crusher, now on its way to Mineral Processing
Solutions in Australia. This high-performance,
heavy-duty jaw crusher plant is designed for
large and medium-scale operators across
quarrying, mining, demolition and recycling
applications.
smooth, continuous flow of material. Additionally, the MT120J
is equipped with a wide bypass chute that optimises material
flow, while the aggressive crushing action of the high swing
jaw encourages efficient material entry into the chamber.
The first MT120J large jaw crusher from MAGNA is now on its
way to Mineral Processing Solutions in Australia
The crusher also offers a fully hydraulic setting adjustment
system, which allows operators to make quick and precise
changes to the crusher settings, enhancing both flexibility and
operational efficiency. The highly efficient direct drive system
supports low fuel consumption and enables the MT120J to be
a cost-effective and environmentally friendly solution. Its
powerful engine operates at low RPM, further reducing fuel
consumption without sacrificing performance. While the first
unit produced is a diesel/direct drive configuration, the
MT120J model can also be built as a fully hybrid unit to utilise
the onboard genset drive system or accept external electricity
supply (MT120Je).
Manufactured at the Terex Crushing Technology Centre of
Excellence in Coalville, the MT120J is a robust addition to the
MAGNA lineup. Featuring an advanced 1200 mm x 820 mm
Terex chamber that is optimised for high-performance
crushing, the MT120J has an output potential of up to 600 tph
(661 US tph), depending on material type and crusher settings,
and is designed to handle challenging and high-volume
operations.
One of the key attributes of the MT120J is its quick set-up
process. The machine includes a ground-level hydraulic folding
feed hopper with a hydraulic locking system, supporting
operators in getting it set up and running efficiently. The
robust feed hopper is wear-resistant, and the stepped self-
cleaning grizzly feeder with under feeder screen provides a
For ease of use, the MT120J is fitted with a modern, user-
friendly PLC control system that includes an auto start facility.
It also comes with radio remote control and MAGNA telemetry
as standard, allowing for intuitive monitoring and control of
the machine. The product conveyor is angle adjustable, which
lowers for easy access and transport, while under-crusher
chassis design offers excellent service and maintenance
access.
The MT120J is also designed with safety and maintenance in
mind, equipped with a dust suppression system to provide
cleaner operations as well as straightforward access to the
power unit canopy for maintenance and service.
"The MT120J is a solution built for high performance and
maximum productivity," said Neil McIlwaine, Business Line
Director for MAGNA. "It has advanced features and durability
that make it the ideal crusher for Mineral Processing Solutions
in Australia, who needs equipment that can keep pace with
the demands of large-scale projects. We look forward to seeing
it deliver exceptional performance and support their continued
success in Australia."
