Hillhead 2026 Preview
Terex Washing Systems to introduce New
AggreScrub™ P80 at Hillhead 2026
Terex® Washing Systems will present the new
AggreScrub P80 Logwasher with PreScreen at
Hillhead 2026, taking place from 23–25 June
2026 in Buxton, England, where the new wet
processing solution is being shown publicly for
the first time on Stand L6.
The AggreScrub™ P80 is a high‑performance wet processing
solution engineered for construction and demolition waste,
excavation material and aggregate applications. Mounted on
a single modular chassis, the plant combines pre‑screening,
logwasher scrubbing, post-screening, contaminant removal
and slurry management within one integrated system,
delivering efficient material separation while maximising
throughput and uptime.
Stand L6
Commenting on the launch, Paul Carolan, recently appointed
Business Line Director for Terex Washing Systems, said,
“Introducing the AggreScrub™ P80 at Hillhead reflects the
increasing demand for compact, high‑throughput wet
processing solutions capable of handling heavily
contaminated material. By combining pre‑screening, intensive
scrubbing and accurate post‑scrub sizing on a single chassis,
the P80 provides a practical way for operators to simplify
plant layouts while achieving more consistent, higher quality
end products.”
Designed to remove clays, silts, organics and lightweight
contaminants, the AggreScrub™ P80 enables operators to
reduce operating costs, streamline plant design and improve
final product quality. Its modular, compact layout also
supports faster transport, installation and commissioning,
making it well‑suited as a core module within modern wet
processing plants.
At the heart of the AggreScrub™ P80 is the PowerScrub™
twin‑shaft logwasher, featuring spiral‑arranged blades that
deliver intensive stone‑on‑stone attrition and continuous
material movement. An adjustable operating angle allows
retention time to be optimised for varying feed conditions,
while independent high‑torque drives enable reliable start‑up
under load, helping to minimise blockages and downtime.
Following the scrubbing
stage, material is
processed by a 2.4 m x
1.2 m triple deck inclined
aggregate screen,
producing up to three
clean, washed products.
Integrated spray bars
deliver an effective
secondary rinse to remove
residual contamination
prior to final sizing.
Lightweight
contaminants, including
plastics and organics, are removed via a dedicated 1.8 m x 0.6
m trash screen, improving final product cleanliness and
protecting downstream equipment. An integrated sump tank
and pump maintains consistent slurry levels to ensure stable
washing conditions.
The AggreScrub™ P80 has also been designed with safety,
durability and ease of maintenance in mind. Fully galvanised
800 mm wide walkways with GRP flooring provide safe,
non‑slip access throughout the plant, while robust wear
protection and maintenance‑friendly access points support
reliable operation in demanding environments.
In addition to the AggreScrub™ P80, Terex Washing Systems
will also display the FM60C from its FM Compact sand
recovery range, which has been designed to deliver cost‑ and
energy‑efficient sand recovery by using centrifugal force
within hydrocyclones to remove clay, silt and slime below 75
microns. The FM60C combines a collection tank, centrifugal
slurry pump, hydrocyclones and a high‑frequency dewatering
screen on a single compact chassis, capable of recovering one
or two grades of sand with low residual moisture content in
the final product.
“The first public showing of the AggreScrub™ P80 at
Hillhead, alongside the FM60C sand recovery unit, reflects key
elements of our wet processing capability,” added Paul
Carolan. “We look forward to welcoming visitors to our stand
to discuss applications, plant configuration and how these
solutions can be integrated into wet processing operations.”
For more information, please visit: www.terex.com/washing
